FC UPC Fiber optic media converter Video Over Fiber Media Converter Rack Mounting

Quick informations:

- Product name: 10 video ways Data Video Optical Converter

- Data way: 5 ways

- Video Way: 16 ways

- Optical way: 1 way

- Optic connector type: FC/UPC

- Fiber mode: single mode, mono mode

- Transfer distance: 20km

- Size: standard 19 inch

Typical Application:
- Intelligent transportation supervisory system (ITS)
- Military Tele-Com projects
- Intelligent Monitor to produce process
- Intelligent Monitor and alarm to factory, coal mine, oil field etc,realize safe and fireproofing
- High-building Security Protection

Specification:
- Monitor center adopt 19 inch 1U rack, Long-distance point adopt mini box
- Simplex fiber singlemode transmit VIDEO/AUDIO/PHONE/DATA
- Data uncompressed fiber transmit
- Automatically compatible with PAL, NTSC and SECAM video format
- Semiduplex/Fullduplex data communication
- Double direction Audio and phone
- Audio/telephone, Ethernet for choice


Features:

- TR/RE pair transports eight channels of high quality

- Composite video in one direction and one channels of data in reverse directions over one optical fiber

- Exceeds rs250c specifications for SNR and Differential Phase and Differential Gain

- 10bit liner PCM video encoding

- 6.5Mhz video bandwidth @-3db >67db SNR Over entire optical rang

- Range up to 30km depending on model

- Compatible with NTSC OR PAL OR SECAM

- Compatible with the network management system

- Data rs485 or rs422 or rs232

Product picutures:

Parameter:

1- Video

Video format NTSC PAL SECAM

Voltage 1vp-p 75Ω

Bandwidth 6.5MHZ -3db

Deferential Gain ≤0.7%

Deferential phase ≤0.7O

Video SNR ≥67dB；over usable fiber

Range for rs250 standard

Encoding 10-bit linear PCM

Sampling rate 5Mhz

Bite rate over fiber one video for 188Mbps

Eight video for 1.44Gbps

Connectors one BNCs

Data RS485

2- Power

Requirements TRANSMITTER (FT-T101d) 0.6A@6vdc

Receiver (FT-R101d) 0.7A@6vdc

3- Physical

Dimensions (in millimeters): 201(w)*195.4(d)*28(h)

Weight (in pounds): 0.68

4- Environmental

Operating temperature -35OC to 70 OC

Storage temperature -50OC to 85 OC

Relative humidity 0% to 95%

5- DATA Illumination

5.1- Transceiver

DATA1: Pin1:no use

Pin2:no use

Pin3:OUTPUT RS485+

Pin4:OUTPUT RS485-

5.2- Receiver

DATA1: Pin1:no use

Pin2:no use

Pin3:INPUT RS485+

Pin4:INPUT RS485-

6- Indicators

TR SYNC (local data in sync)

PWR (power natural)

RE CD (fiber established)

SYNC(TR RE in sync)

PWR(power natural)

7- OPTICAL CONNECTOR: FC/PC

OPTICAL wavelength:

Positive direction for 1310 um

Back direction for 1550 um

Dimension:

Applications:

Ordering informations:

Package:

Carton box, wooden pallet

Shipping:

- By International Express such as TNT, DHL, UPS, etc

- By Air: CA, HA, AA, EA, etc

- By Sea
